Shuangda Valve CO.,LTD (hereafter called SDV)

✖
    Trunnion Ball Valve

    Trunnion Ball Valve

    SDV trunnion ball valves are offered in 2 PC side entry, 3 PC side entry, welded body and top entry design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials.  FBV trunnion ball valves are manufactured according to API 6D Design and fire safe tested per API 6FA and API 607 Standard.

    PRODUCT RANGE

    Sizes NPS 2 to NPS 48

    Class 150 to Class 2500

    DESIGN FEATURES

    Full or Reduced Bore

    RF, RTJ, BW or PE

    Side entry, top entry, or welded body design

    Double Block & Bleed (DBB)

    Double Isolation & Bleed (DIB)

    Emergency seat and stem injection

    Anti-Static Device

    DESIGN STANDARD

    Design & manufacture according to API 6D, API 608, ISO 17292

    Face-to-face according to API 6D, ASME B16.10

    End Connection according to ASME B16.5, ASME B16.47, MSS SP-44 (NPS 22 Only)

    Test & inspection according to API 6D, API 598

    Fire safe design according to API 6FA, API 607

    Also available per NACE MR-0175, NACE MR-0103, ISO 15848
